Chain Link Fence Description
Features:
1.Woven diamond pattern provides strong, durable and flexible construction
2.Does not break, sag or roll up at the bottom
3.Long lasting service life
4.Strong, durable and flexible construction
5.Convenient transportation and installation
6.Weather resistance, corrosion and alkali resistance
7.Provides optional security and protection
Chain Link Fence Specification
| Chain Link Fence | |
| Material | Galvanized iron wire or PVC coated iron wire |
| Surface Treatment | PVC coated, PVC sprayed, electric galvanized, hot dipped galvanized |
| Wire Thickness | 1.0-6.0mm |
| Mesh Opening | 20x20mm,50x50mm,60x60mm,80x80mm,100x100mm etc |
| Mesh Height | 0.5m-6m |
| Mesh Length | 4m-50m |
| Post & Rail Diameter | 32mm, 42mm,50mm,60mm,76mm,89mm etc |
| Post & Rail Thickness | 1.5mm,2.0mm,3.0mm,4.0mm,5.0mm etc |
| Galvanized Chain Link Mesh | |||
| Mesh | Wire Diameter | Width | Length |
| 40*40 mm | 1.8 - 3.0 mm | 0.5 - 4.0m | 5 - 25 m |
| 50*50 mm | 1.8 - 3.5 mm | 0.5 - 4.0m | 5 - 25 m |
| 60*60 mm | 1.8 - 4.0 mm | 0.5 - 4.0m | 5 - 25 m |
| 80*80 mm | 2.5 - 4.0 mm | 0.5 - 4.0m | 5 - 25 m |
| 100*100 mm | 2.5 - 4.0 mm | 0.5 - 4.0m | 5 - 25 m |
Appilcation:
Chain link fences are mainly used for road, security area, building area, super highway, railway, airport playground and gardens, highway, port, residence, et
